Feature:
1. GOOD PERFORMANCE: This receiving card has 8 HUB75 interfaces, 192 × 1024 PWM pixel points, with support for any exchange of network ports, with high refresh rate, high grayscale, and high brightness.
2. HIGH COMPATIBILITY: Supports conventional, PWM, and vision core chip, with any scanning type from static to 128 scans. A single set of data can support any wiring within 13312 pixels, with diverse wiring directions.
3. RGB DATA FUNCTION: LED display screen synchronous receiving card, supporting 32 sets of parallel RGB full color data or 32 sets of serial RGB data, expandable to 128 sets of serial RGB data.
4. IMAGE EFFECTS: This receiving card supports a refresh rate of up to 3840Hz, ensuring smoother image effects and supporting 16 digit grayscale levels to present more delicate and natural images.
5. MULTIPLE INTERFACES: The receiving card supports multiple input interfaces such as HD multimedia interface, DVI, SDI, VGA, etc. With good stability, it can meet the needs of different places and needs.
6. 1GB STORAGE SPACE: Built in 1GB of storage space, capable of storing a large number of images and videos, easy for users to quickly access, with high stability and reliability, ensuring long term operation.
7. SCREEN LAYOUTS: The LED display screen receiving card supports multiple screen layouts, including point to point, linear, array, etc., can be flexibly combined according to actual scene needs.
Specification:
Item Type: Receiving Card
Working Voltage Range: DC3.3-6V
Control System Parameters:
General: 8 HUB75 interfaces, 128 x 512 pixels
PWM: 192 x 1024 pixels
Vision Core: 162 x 1024 pixels
Support for any exchange of network ports, regardless of input and output, and use it freely
up to 65536 gray level
Display Module Compatibility:
Chip: Support conventional chips, PWM chips, and vision chips
Scan Type: Any scan type between static and 128 scans
Module Specification: Single set of data can support any wiring within 13312 pixels
Cable Layout Direction: Supports connecting from left to right, from right to left, from top to bottom, and from bottom to upper level
16 sets of parallel RGB full color data or 32 sets of serial RGB data, expandable to 128 sets of serial RGB data
Data Group Number:
Data sets can be freely exchanged
Data discounts support horizontal discounts of 20% to 80% and vertical discounts of 20% to 40%
Module point extraction, row extraction, and column extraction support for arbitrary point extraction, row extraction, and column extraction
Comprehensive Monitoring:
Monitor the total number of data packets and error packets on the network cable, assist in checking network quality, and eliminate hidden dangers
Point by point correction
Brightness correction support
Chroma correction support
Other Functions:
Redundant backup supports loop backup and firmware program backup
Optional functional variant construction
Package List:
1 x Receiving Card
