Feature:
1. High compatibility, potentiometer principle, 0100percent given input voltage (changes with displacement).
2. Adopt plug type, convenient and practical, no noise output, smooth engineering rod.
3. Using for Hessman plug to resist oxidation, exquisite workmanship.
4. Reduce signal transmission loss, highdefinition sound quality, compatible with all devices.
5. The highest IP67 protection level, good protection effect.
Specification:
Item Type: Displacement Sensor
Material: Stainless steel
Electrical Stroke: Range + 3mm
Resolution Resolution: Infinite uninterrupted analysis
Repeatability: 0.01mm
Normal Working Current Of Sliding Brush: less than 10microamps
The Maximum Current Of The Sliding Brush When Causing The Fault: 10mA
Insulation Resistance (500VDC, 50Hz): more than 10M Ohm
Insulation Strength (500VAC, 50Hz): less than 100microamps
Shell Length (A): Range + 78.5mm
Mechanical Stroke (B): Range + 8mm
Maximum Load Of Pull Rod: 50KG
Work Force:
Horizontal direction <10N
Vertical direction less than 10N
Vibration Resistance Standard: 5 ... 2000Hz, Amax = 0.8mm, amax = 20g
Shock Resistance Standard: 50g, 11ms
Operating Temperature Range: 60 ... + 150 celsius
Life: > 100 * 10 ^ 6 times
Maximum Operating Speed: 10m S, maximum operating acceleration 10m s2
Protection Level: Highest IP67 (DIN40500 IEC529).
Package List:
1 x Displacement Sensor1 x Plug3 x Accessories4 x ScrewHigh compatibility, potentiometer principle, 0100percent given input voltage (changes with displacement).
Adopt plug type, convenient and practical, no noise output, smooth engineering rod.
Using for Hessman plug to resist oxidation, exquisite workmanship.
Reduce signal transmission loss, highdefinition sound quality, compatible with all devices.
The highest IP67 protection level, good protection effect.
