Interface: USB
Resolution: 1D (Code39): 0.076mm, 2D (DataMatrix): 0.106mm
Light Source: Visible LED, 650nm±20nm
Light Receiver: CMOS Image Sensor (1280 x 960 pixels)
Scan Angle: 50° Horizontal, 30° Vertical
Read Depth:
Code: Cell/Bar Dimensions Distance
Code39: 0.076mm, 100-200mm
UPC:
0.190mm, 50-205mm
0.330mm, 50-275mm
Data Matrix: 0.106mm, 9.5-120mm
0.127mm, 9.5-140mm
0.160mm, 85-160mm
0.254mm 40-200mm
0.528mm 40-310mm
[Readable Width]
(Barcode Width) Less than 280mm
[Input Power] DC +5V ±5%
[Current Consumption] 80mA
[Operating Temperature] 0°C to 50°C
[Ambient Lighting] -20°C to 70°C
[Humidity] 96,000 lux
[Humidity] 20% to 95%
[Impact Resistance] Normal operation after a 1.8m drop onto concrete
[Dimensions] 71.13(L) x 62.61(W) x 169.27(H) mm
[Weight] 150g (unit only)
[Cable] 1.5m straight cable
[Linear]
UPC-A, UPC-E, EAN-8, EAN-13, JAN-8, JAN-13 ISBN,
Codabar (NW-7), Code 39, Code 93, Code 128, GS1-128, Code 11,
MSI, Interleaved 2 of 5, Matrix 2 of 5 GS1 DataBar
(Omni-direction, Limited, Expanded) Plessey Telepen
[2D]
QR Code, GS1 Composite, DataMatrix, PDF417, MicroPDF,
MaxiCode, Aztec, Codablock A, F, TLC39
*Japanese reading software is compatible with Windows XP (SP3) and later.
Supports a reading distance of 0mm to a maximum of 500mm for alphanumeric codes, and a reading width of up to 280mm. Capable of reading 2D codes with Japanese characters and barcodes displayed on LCD screens.
This barcode reader supports 2D codes (QR Code (Model 1, Model 2), GS1 Composite, DataMatrix, PDF417, MicroPDF, MaxiCode, Aztec, Codablock A, F, TLC39). Of course, it can also read 1D codes (JAN, UPC, ISBN, etc.). The included software can even read QR codes with Japanese characters!
The setup manual included with the product is in Japanese. You can set the volume and disable codes, etc. *The tablet in the image is sold separately. Only the barcode reader is included.
It is recognized using keyboard emulation, so the scanned barcode data can be entered into places where keyboard input is possible in browsers, Excel, etc.
