Output Voltage : DC 5-26V
Origin : Mainland China
Type : Mini Amplifier
Channels : 2 (2.0)
Input Type : USB,Micro-USB,Bluetooth
Output Type : LINE OUT (AUDIO OUT)
Package : Yes
Bluetooth : Yes
Body Material : Metal
WIFI : No
DSD (Direct Stream Digital) : No
Recommended Headphone Maximum Impedance : 32 - 50 Ohm
Built-in Battery : No
High-concerned chemical : None
Note:This product requires self-installation.
--------------------------------------------------
C50L Features:
Stepless tuning with smooth operation, one-touch start/stop.
Controllable via mobile app (Sinilink) for faster, more convenient operation.
Delivers refined sound quality.
Compact size for easy portability.
Includes reverse polarity protection, short-circuit protection, and self-recovery overheat protection.
Specifications:
Primary Color: Black
Bluetooth Version: 5.0
Transmission Range: 15 meters
Compatible Speakers: 0-200W 4Ω/8Ω/16Ω
Output Power: 50W x 2
Product Dimensions: 75x50x18 mm / 3.0x2.0x0.7 inches
Package Dimensions: 115x60x35 mm / 4.5x2.4x1.4 inches
Package Contents:
1x Power Amplifier Module (requires self-assembly)
--------------------------------------------------
C100L Features:
1. Independent treble and bass adjustment for left and right channels, plus dedicated subwoofer control with 360-degree stepless tuning.
2. Mobile app control compatible with Apple and Android systems (search Sinilink on Google Play Store to download).
3. Premium rotary encoder knob for smooth 360-degree stepless tuning. Single-click to start/pause tuning; long press for quick operations.
4. Equipped with large-area heat sinks coated with specialized thermal grease, complemented by copper cooling structures on the sides, doubling heat dissipation area to ensure stable operation at full power and high loads.
5. Supported Audio Inputs: Compatible with Bluetooth 5.0, AUX audio input, sound card input, and USB flash drive playback (USB drives must use FAT32 file system, supporting up to 32GB capacity).
Specifications:
Number of Channels: Left/Right Stereo
Speaker Impedance: 4-8 ohms, 30-300 watts
Power Supply Voltage: DC 5-26V (higher voltage increases output power)
Bluetooth Version: 5.0
Transmission Range: 15 meters (unobstructed environment)
Volume Control: 360-degree stepless encoder tuning
Audio Inputs: Bluetooth + AUX + USB storage + USB sound card
Audio Outputs: Passive speakers + 3.5mm jack
Output Power: 100W x 2
Heat Dissipation: Heat sink + chassis
Protection Mechanisms: Reverse polarity protection, short-circuit protection, self-resetting thermal protection
Additional Features: Supports Android/iOS mobile apps
12V-8Ω: 12W+12W, 4Ω: 22W+22W
19V-8Ω: 28W+28W, 4Ω: 55W+55W
22V-8Ω 37W+37W, 4Ω 72W+72W
24V-8Ω 51W+51W, 4Ω 100W+100W
Dimensions (including housing): 58mm x 53mm x 18mm
