Feature:
1. Multiple Measurements: DC voltage current measurement, True RMS AC voltage current measurement, frequency, resistance, capacitance, diode on off test, continuity and temperature.
2. TFT LCD Screen: 3.5 inch 480*320 high resolution TFT LCD screen with backlight, 55,000 counts, DC voltage accuracy up to 0.05percent , dual line display supported(AC voltage or current and frequency), providing a clear and precise display.
3. Fast Measurement: up to 65 readings per second, fast \u0026 accuracy.
4. User friendly Interface: with an easy to use interface that displays results in form of a table, you can access, store, process and manage your data.
5. Rechargeable Digital Multimeter: built in with large capacity lithium battery, supports multiple power supply methods to extend the measurement time duration, making onsite measurement possible.
6. Data Record Function: including manual record and auto record. Both records share a table of data stored in internal storage. The maximum number of recorded points is 1,000, the auto recording time interval can be set from 15ms to 9999s. After collecting the data, it can be exported to your computer, and you can read and process the recorded data with the computer.
Specification:
Features:
Multiple Measurements: DC voltage current measurement, True RMS AC voltage current measurement, frequency, resistance, capacitance, diode on off test, continuity and temperature.
TFT LCD Screen: 3.5 inch 480*320 high resolution TFT LCD screen with backlight, 55,000 counts, DC voltage accuracy up to 0.05percent , dual line display supported(AC voltage or current and frequency), providing a clear and precise display.
Fast Measurement: up to 65 readings per second, fast & accuracy.
User friendly Interface: with an easy to use interface that displays results in form of a table, you can access, store, process and manage your data.
Rechargeable Digital Multimeter: built in with large capacity lithium battery, supports multiple power supply methods to extend the measurement time duration, making onsite measurement possible.
Data Record Function: including manual record and auto record. Both records share a table of data stored in internal storage. The maximum number of recorded points is 1,000, the auto recording time interval can be set from 15ms to 9999s. After collecting the data, it can be exported to your computer, and you can read and process the recorded data with the computer.
Math Function: the multimeter can do calculations for you (relative, max. min. average, dBm), saving time and effort.
Light Weight & Small Size: measured size in 7.9*3.4*2.5 inch, and weighted only 16.6oz(470g), the desktop multimeter with diverse functions is good looking, powerful and portable for test work.
Temperature Measurement: it can cooperate with K type temperature probe(NOT included) for temperature measurement, the temperature display supports celsius (Celsius), Fahrenheit (Fahrenheit), K(Kelvin). Built in thermocouple cold junction compensation.
Specifications:
Material: ABS
Display: 3.5 inch TFT LCD (480*320 resolution)
Max. Display: 55,000 counts
DC Voltage: 50mV 500mV 5V 50V 500V 1000V
True RMS AC Voltage: 500mV 750V
DC Current: 500microamps 5000microamps 50mA 500mA 5A 10A
True RMS AC Current: 500microamps 500mA, 5A 10A
Resistance: 500 Ohm 5k Ohm 50k Ohm 500k Ohm 5M Ohm 50M Ohm
Frequency: 10Hz 60MHz
Capacitance: 50nF 500uF, 5mF 50mF
Diode: 3V
Continuity: 1000 Ohm
Temperature: K type, PT100 (K type temperature probe is NOT included)
Data Logging Interval: 15ms 9999.999s
Data Logging Length: 1,000 points
Battery: 2 * 3.7V 2200mAh
Item Size: 200 * 86.5 * 64mm 7.87 * 3.41 * 2.52in
Item Weight: 619g 21.86oz
Package Weight: 819g 28.89oz
Package Size: 24.5 * 17 * 8cm 9.65 * 6.69 * 3.15in
Packing List:
1 * Digital Multimeter
1 * Pair of Test
2 * Alligator Clip
1 * USB Data Cable
1 * USB to DC Cord
1 * Quick Guide (English)
Package List:
1 * Digital Multimeter
1 * Pair of Test
2 * Alligator Clip
1 * USB Data Cable
1 * USB to DC Cord
1 * Quick Guide (English)
