Modular Switch Disconnector 63A 2P 16Ka Frx302 406528

Manufacturer's index: 406528

Maximum rated operating voltage Ue AC [V]: 455

Suitable for 4-hole front mounting: No

series: FRX300 switch disconnectors

Degree of protection (IP) of the front: IP20

Built-in motor drive: No

Rated continuous current Iu [A]: 63

Rated conditional short-circuit current Iq [kA]: 16

Device construction: Complete device in housing CN: 85366990 Length: 150 EAN: 3245064065283 As a safety switch: Yes As a main switch: Yes As an emergency stop switch: Yes Number of poles: 2 Suitable for installation in distribution boards: Yes Suitable for front mounting centrally: No Suitable for flat mounting: No Optional motor drive: Yes Optional shunt release: Yes PKWiU: 27.12.40.0 Type of switching element: Lever Type of main circuit connection: Screw connection Width: 150 Weight: 0.2000 Height: 100 With locking mechanism: Yes
