Quantity : 1
High-concerned chemical : none
Package : SOP
is_d : Yes
Supply Voltage : DC 9V-30V
Application : MOBILE PHONE
Type : Module
Brand Name : DIY NOW
Origin : Mainland China
Condition : New
Operating Temperature : -40-125℃
Input Interface : DC 5.5*2.1
Output Interface : USB A/Type C
Input Voltage : DC 9V-30V (Step-down type)
Recommended Current : 5A
No-load Current : 3-5mA
Features:
1. Supports multi protocol fast charging and is compatible with most mainstream mobile phone s on the market.
2. The input voltage width is up to 9V-30V, suitable for various types of car power systems.
3. Dual USB ports for independent output, A port 30W+C port 20W efficient allocation.
4. Built in anti reverse protection, safe and reliable, extends the life of the module.
5. Wide working temperature range, stable operation from -40 ℃ to 125 ℃.
Parameters:
Input interface: DC 5.5 * 2.1
Output interface: USB A/Type C
Input voltage: DC 9V-30V (step-down type) (The input power must be greater than the output power, and the power is equal to the voltage multiplied by the current converted by itself. In order to ensure that the voltage is sufficient, the current must also be sufficient.)
Recommended current: 5A
No load current: 3-5mA
Working temperature: -40-125 ℃
Compatibility Protocol:
Compatible with common USB TYPE-A fast charging protocols: BC1.2, APPLE2.4A, QC2.0/QC3.0/QC3.0+, FCP, SCPHISCP, low-voltage direct charging, etc. FCP supports regular cables, but SCP protocol requires original cables.
Compatible with QC3.0, QC3+, UFCSSUPERWOOC, SUPERDASHAWARP, FCP, SCP, AFC/APPLE 2.4A, etc., supporting Mijia ordinary fast charging QC3.0, QC3+, Mijia private CHARGE TURBO 27W (with line requirements), supporting AFC, FCP (1st generation fast charging) and SCP (2nd generation fast charging), OPPO series V0OC, DASH, WARP (all 1st generation versions, requiring line support), VIVO IGOO series, etc., most of which also support fast charging. Attention: Not all models can use fast charging, and it is normal for a few models to not be able to use fast charging!!!
Application Scenario:
Suitable for providing dual device fast charging for cars, trucks, RVs, etc;
Suitable for the interior of industrial equipment such as construction vehicles and special operation vehicles, as a USB charging interface expansion module;
Suitable for electronic enthusiasts to DIY modify and create personalized charging devices.
Package Include:
1X module
label:yes
Connector type: type-c
Number of ports: 1 port
