Interface configuration: Type-C male head+Type-C female seat, male and female direct connection structure
Protocol standard: USB 2.0 (up to 480Mbps), supports USB 2.0 data transfer, Type-C analog audio headphone signal
Pin specifications: All 16P pin positions are independently led out to solder pads, and each signal is separately exposed for easy measurement and wire flying
Product structure: Male and female up and down alignment layout, signal one-to-one correspondence through no switching chip, passive adapter board
Functional applications: wire conductivity testing, audio headphone signal debugging, Type-C wire repair, DIY wire modification, oscilloscope signal capture
Pad design: Large square pads for convenient multimeter probe measurement, wire soldering, and fly wire modification
Applicable signals: D+/D - data, VBUS power supply, GND, CC, SBU1/SBU2 audio differential signal
Reminder: Only USB 2.0, does not support USB 3.0 high-speed data, PD fast charging communication debugging
Equipped with Type-C male plug and Type-C female socket, straight-through passive adapter design.
Compliant with USB2.0 specification up to 480Mbps, support USB2.0 data and Type-C analog earphone audio signal.
Complete 16 pins fully broken out to independent solder pads for convenient measurement and wire modification.
Passive straight connection without built-in IC, original signal transmission with little distortion.
Large-size solder pads support multimeter probe testing, soldering and flying wire modification.
Ideal fixture for cable continuity test, earphone audio debugging, Type-C cable repair and signal capture.
Suitable for maker experiment, electronic maintenance workshop and lab signal detection work.
Notice: Only USB2.0 version,NOT support USB3.0 high speed and PD communication debugging.
