Feature:
1. Wireless WIFI BT Adapter: W97S is an intelligent dual band wireless network card composed of 2.4GHz and 5.8GHz, and one of the channels can be freely selected. Compared with the single frequency wireless network card, it has a higher wireless transmission rate, stronger anti interference, and stronger wireless signals and higher stability.
2. 866Mbps Wireless Network Card Rate: W97S adopts a new generation of 11AC technology, uses a wider bandwidth and higher modulation efficiency in the 5.8G frequency band, wireless transmission can reach 866M, watching high definition video, online games and other network applications are smoother, and the o visual experience is better good.
3. Wireless Network Card Function: W97S wireless network card, suitable for receiving wireless network signals such as WIFI WLAN, supports analog AP function, which is convenient for users to realize multi person sharing network access through the network card; support WPA WPA2, high security level, can effectively avoid network rubbing , And solve the safety problem of using public WIFI.
4. BT Transmission and Reception: BT 4.1 high speed transmission, stable and smooth performance; allows you to connect the computer and BT h enabled devices for data transmission, editing or printing, the connection distance can reach 10m, to achieve long distance transmission.
5. Strong Compatibility: W97S plug in wireless WIFI BT adapter, in for WIN7, for WIN8, for WIN10 system will usually automatically install related drivers, directly plug it in to connect to the router. If you can"t connect to the computer when you plug it in, you need to install the CD ROM driver. for WIN XP VISTA is a CD ROM driver must be installed.
Specification:
Item Type: Network Card
Model: W97S
Material: ABS
Colour: Black
Wireless Network Card:
Network Card Interface Type: USB3.0
Working Channel: 1~11 (USA, Canada), 1~13 (China, Europe), 1~14 (Japan)
Speed: 1200Mbps
Frequency Range: 2.4G~5.8G
Protocol Standard: iEEE802.11a b g n ac WIFI Compliant
Modulation Method: 802.11b g n a ac:OFDM(BPSK,QPSK,16QAM,64QAM,256QAM)
Wireless Rate:
802.11a: 6, 9, 12, 18, 24, 36, 48, 54Mbps
802.11b: 1, 2, 5.5, 11Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, 54Mbps
802.11n: 6.5~300Mbps
802.11ac: Up to 867Mbps
Transmitting Power:
802.11b11Mbps:16dBm+-1.5dB at EVM less than -9dB
802.11g54Mbps:15dBm+-1.5dB at EVM less than -25dB
802.11nMCS7:14dBm+-1.5dB at EVM less than -28dB
802.11a54Mbps:13dBm+-1.5dB at EVM less than -25dB
802.11nMCS7:12dBm+-1.5dB at EVM less than -32dB
802.11acMCS9:10dBm+-1.5dB at EVM less than -32dB
Working Mode: Wireless Internet, Ad hoc Mode (Point To Point), Infrastructure Mode, Software Application, Wireless Direct Connection, BT4.1, Pico Net Distributed Network
BT Adapter:
BT Version: BT V4.1
BT Interface: USB2.0
Operating Frequency: 2.4G: 24000GHz~2.4835GHz
Number of Channels: 79
Modulation Method: FHSS,GFSK,DPSK,DQPSK
Transmission Distance: Approx. 10m32.8ft
Support System: For Windows XP, For Vista, For Win7, For Win8, For Win10, For linux, For Android.
Package List:
1 x Network Card1 x Driver Cd1 x Manual
