Feature:
1. The foot valve switch is panel mounted, with large contact area and wide pressure resistance range.
2. Using the foot pedal, the switch can be controlled without power supply, which is energysaving and environmentally friendly.
3. Made of aluminum alloy, it is resistant to friction and can be stepped on for a long time without being deformed.
4. Standard 5 way 2 position foot valve, standard pipe thread, stable performance after installation.
5. Widely used in medical equipment, stamping equipment, welding equipment, textile equipment, printing machinery.
Specification:
Item Type: Foot Valve Switch
Model: 4F21008
Material: Aluminum alloy
Type (Channel Position): Pilot type
Working Temperature: Normal pressure
Working Medium: Compressed air
Maximum Working Pressure: 0.8Mpa
Maximum Pressure Resistance: 1.0Mpa
Port Size: G14
Specification: 5 way 2 position
Application: Foot switches are widely used in medical equipment, stamping equipment, welding equipment, textile equipment, and printing machinery..
Package List:
1 x Foot Valve Switch
Note:
1. Before use, check the components to see if they are damaged during transportation, and then install and use.2. Please pay attention to whether the gas flow direction and the connection pipe are correct when installing.3. Pay attention to dust. When connecting the pipeline, the antidiarrheal tape should not be wrapped over the tooth end surface, and attention should be paid to eliminate the metal particles, dust and oil stains in the pipe joints and the pipe.The foot valve switch is panel mounted, with large contact area and wide pressure resistance range.
Using the foot pedal, the switch can be controlled without power supply, which is energysaving and environmentally friendly.
Made of aluminum alloy, it is resistant to friction and can be stepped on for a long time without being deformed.
Standard 5 way 2 position foot valve, standard pipe thread, stable performance after installation.
Widely used in medical equipment, stamping equipment, welding equipment, textile equipment, printing machinery.
