Features:
brand new and high quality
Products with different R and B values can be provided, with strong interchangeability and high precision.
The structure is simple, the installation is simple, and the waterproofness is good.
The temperature sensor has high sensitivity and rapid response.
The use temperature range is wide, the stability is good, and the reliability is high.
This NTC temperature sensor is suitable for electric kettles, water heaters, wall-hung boilers, ice crushers, bread machines, ovens, microwave ovens, etc.
Specifications:
Material: Plastic + Metal
Weight: 12g
Size: As picture shows
Operating Temperature Range: -40℃～+150℃
Dissipation Power Coefficient: ≥5 mW/℃ (in Static Air)
Maximum Rated Power: 45mW
Thermal for Time Constant: ≤7S (in Static Air)
Temperature Coefficient of Resistance: -2～-5%/℃
Insulation Performance: 500V for DC Test Single Insulation Resistance ≥100mΩ
Withstand Voltage Performance: 1500V Ac, 5s, 0.5mA Without Breakdown
Package Includes:
1x Temperature Sensor
note:
1.Please allow 1-2cm errors due to manual measurement, make sure that you do not mind before you order.
2.Due to the difference between different monitors, the picture may not reflect the actual color of the item.
