1. MAIN PURPOSE: The vector impedance analyzer is mainly used to test antenna impedance, RF device impedance, circuit board impedance, etc.
2. MEASURING PARAMETER: Can be used to measure resistance, reactance, standing wave, and S11, with a wide measurement range, high resolution, and accuracy.
3. BUILT IN BATTERY: The antenna analyzer has built in 2000mAH polymer lithium battery, USB interface for charging, can operate continuously for over 4 hours.
4. OTHER FUNCTIONS: The single point measurement result is 4 digit significant figures, 280 scanning points, with calibration function, stable and reliable.
5. 2.4IN TFT SCREEN: The antenna impedance analyzer adopts 2.4 inch TFT screen, lightweight and portable, suitable for outdoor and high altitude work.
Specification:
Item Type: Antenna Analyzer
Working Frequency: 137.5MHz-2700MHz
Frequency Step: 1kHz
Display: 2.4 Inch TFT Resolution 320x240 (QVGA)
Battery: 2000mAH Polymer Lithium Battery (built in battery)
Power Consumption: Charging Current: 400mA
Charging Interface: USB (only used as a charging interface)
Automatic Shutdown: Settable (continuously on, 5-60 minutes optional)
Measurement Parameters: Resistance, Reactance, Standing Wave, S11
Resolution: 4 Significant Value
Frequency Accuracy: Connector: SMA-K
Measurement Range:
Impedance: Frequency 1300MHz (absolute impedance value)
Standing Wave: Frequency 1300MHz
S11: 0dB to -50dB
Error (Single Point Measurement):
Impedance: Z 1.3GHz
S11: 0dB to -10dB, -10dB to -20dB, -20dB to -40dB
Standing Wave: Directionality (After Calibration): 137.5MHz, 34.375MHz -2GHz, 2GHz -2.7GHz
Scan Points: 280
Output Level: -18dBm
Working Temperature: 5℃-40℃
Atmospheric Pressure: 860hPa-1060hPa
How to Use:
Power On: Hold down the CTRL key and press the OK key to power on.Power Off: Long press (>2S) OK key to power off.
Package List:
1 x Antenna Analyzer
1 x USB Cable
1 x User Manual
